MOQ

1 set

Payment Terms

T/T

Footprint

L: 650mm W: 600mm H: 760mm (both two joysticks included)

Delivery Time

Standard products are delivered within 25 days, excluding customized products.

Transport Package

Wooden Case

Customized Service

Support (Color, Logo, Test Fixture,Module,etc)

HS Code

44031644Q9

Certification

ISO9001

Service Process

Provide one-stop pre-sales, in-sales services, after-sales training, ensuring worry-free use for customers.

Technical Support

Provide online support and technical consultation.

Sample Policy

Free sample testing.

After-Sales Support

1-year warranty period, supporting parts replacement and repair.

Production Capacity

200PCS/ Year pcs/ Year

Weight

Approx. 80KG

Power Supply

110V/220V;  @0.30A;  50/60Hz

Pneumatic Supply

4.5-6 Bar

Control Computer

Intel / Windows10 PC

Operating System

Windows10/ Windows11 (with optional trinocular microscope& CCD high-definition camera)

Test Mode

Manual ( The manual module exchange allows for easy switching to accommodate different types of tests)

Platform Leveling Accuracy

360 degrees, can be adjusted to each platform

XY Axis Effective Travel

100 mm*100 mm，and can vacuum platform can be extended to 200mm x 200 mm, with a maximum test load of 200 KG

XY Axis Moving Speed

Uses precision XY table with independent control, maximum movement speed of 6 mm/S

XY Axis Repetition Accuracy

Repeatability ±5μm, movement accuracy ≤0.125mm, with precision ≤2μm

Z Axis Effective Travel

100mm，with a maximum test load of 20KG

Z Axis Vertical Moving Speed

Uses precision Z-axis control, maximum speed of 8 mm/S

Z Axis Repetition Accuracy

Repeatability ±2μm, travel within ±1μm

Test Accuracy

The equipment can test with 0.003%, accuracy of ±0.025% per tested part

Calibration

The equipment needs regular calibration (provided with standard calibration kit)

Quality Assurance

The device comes with a 1-year warranty, including hardware and software upgrades (not covering human damage)

BS250G

25g、50g、100g、250g

WP25G

2.5g、5g、10g、25g

BS1KG

100g、200g、500g、1kg

WP50G

5g、10g、25g、50g

DS5KG

500g、1kg、2.5kg、5kg

WP100G

10g、25g、50g、100g

DS10KG

2.5kg、5kg、7.5kg、10kg

WP200G

25g、50g、100g、200g

DS20KG

2kg、4kg、10kg、20kg

WP1KG

100g、250g、500g、1kg

DS50KG

10kg、20kg、40kg、50kg

WP5KG

500g、1.25kg、2.5kg、5kg

DS100KG

10kg、20kg、50kg、100kg

WP10KG

1kg、2.5kg、5kg、10kg

DS200KG

20kg、40kg、100kg、200kg

WP20KG

2.5kg、5kg、10kg、20kg

Pressure Testing

Linear Calibration Points

Force Testing- Tweezer Pulling

Linear Calibration Points

PP100G

10g、25g、50g、100g

TP100G

10g、25g、50g、100g

PP5KG

500g、1.25kg、2.5kg、5kg

TP1KG

100g、250g、500g、1kg

PP50KG

5kg、10kg、25kg、50kg

TP5KG

500g、1.25kg、2.5kg、5kg

Customizable Testing Modules based on specific range requirements.
